On grid solar system

Name: On grid solar system
Brand: Green And Efficient Energy Services
Price: 70000.0 INR
Availability: InStock

Price 70000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

On grid solar system Specification

Input Voltage
Typically 370-600V DC (string input inverter)

Efficiency
Panel efficiency 16-21% (depends on brand/model)

Maintenance Type
Low, Periodic panel cleaning and inverter inspection

Features
Zero Battery, Grid Export, Net Metering Compatible, Modular Expandability

Product Type
On Grid Solar System

Material
Crystalline Silicon (Aluminum mounting structure)

Number of Cells
60/72 cells per panel

Power
Typically from 1 kW to 30 kW or more (customizable as per requirements)

Operating Temperature
-40C to +85C

Max Voltage
Depends on system configuration, typically 600-1000V DC

Max System Voltage
1000V DC

Output Voltage
230V/415V AC (Single/Three Phase as per system design)

Cable Length
As per installation requirements (standard: 5-25 meters)

Switch Mode
Automatic, Inverter-based Grid Synchronization

Size
Panel size generally ~ 2 m x 1 m per module

Dimension (L*W*H)
Variable as per system size and panel configuration

Color
Blue/Black (typical of monocrystalline/polycrystalline panels)

Weight
Approximately 20-25 kg per panel

Application
Residential, Commercial, Industrial - suitable for grid-connected power generation

Type Of Technology
Photovoltaic (PV)

Installation Type
Rooftop Mounting (fixed tilt or adjustable)

Wind Load Capacity
Withstands up to 150 km/h wind speed

Ambient Humidity
0%-95% non-condensing

Mounting Structure
Hot-dip galvanized iron/aluminum for corrosion resistance

Fire Safety
Compliant with standard electrical/fire safety norms

Annual Energy Yield
Approx. 1400-1600 kWh per kW per year (site dependent)

Inverter Type
String Inverter / Micro Inverter as per system design

Environmental Suitability
UV and weather resistant components

Protection
Inbuilt surge protection, earthing kit included

Expansion Capability
Modular expansion possible per roof area

Panel Type
Monocrystalline or Polycrystalline Silicone

Panel Glass
Tempered low-iron glass, anti-reflective coating

Output Current
As per output power and voltage; generally 2A-15A per string

Monitoring
Remote monitoring via WiFi/GPRS (optional)

About On grid solar system

Experience opulent energy solutions with our hot-selling On Grid Solar System, designed for instant savings and majestic reliability. Choose between superlative monocrystalline or polycrystalline panels for optimal energy capture. The robust mounting structure uses hot-dip galvanized iron or aluminum for unmatched corrosion resistance. Inbuilt surge protection and earthing kits guarantee safety, while the tempered low-iron glass with anti-reflective coating maximizes efficiency. Smart monitoring, modular expansion, and instant checkout make grid integration effortless. Enjoy seamless grid export, net metering compatibility, and unparalleled durability under diverse climatic conditions.

Unmatched Reliability and Versatility: On Grid Solar Solutions

Our On Grid Solar System stands apart through primary competitive advantages like high-efficiency photovoltaic panels, scalable modular design, and weather-resistant assembly. Its superlative components are engineered for seamless operation across residential, commercial, and industrial applications. The versatile system ensures zero battery maintenance and full compatibility with grid export regulations, positioning it as the preferred choice in diverse application media. Easy expansion and remote system monitoring deliver dependable performance and future-proof capability for businesses and homeowners alike.

Transparent Payment and Export Terms for Global Reach

We ensure secure and transparent transactions, with competitive rates and clear proposal amounts tailored to project needs. Our preferred payment terms accommodate flexible arrangements for both domestic and export clients. Goods transport operates through major FOB ports, guaranteeing punctual delivery and cost-effective logistics. With instant checkout, customers enjoy swift processing from proposal acceptance to product dispatch, supporting hassle-free integration for global clients seeking sustainable solar solutions.

FAQ's of On grid solar system:

Q: How does the On Grid Solar System achieve instant savings?

A: The On Grid Solar System generates electricity directly from sunlight, allowing users to offset grid electricity use and reduce monthly utility bills. Thanks to net metering compatibility, any excess power produced is exported to the grid, earning additional credits or income for users, thereby delivering instant financial savings.

Q: What is the process for installing the On Grid Solar System?

A: Installation involves a site assessment, tailored system design (choosing monocrystalline or polycrystalline panels), mounting structure setup, panel and inverter installation, electrical connection to the grid, and commissioning. Our system includes surge protection and earthing kits, with all components tested for compliance and performance.

Q: When is remote monitoring for the system recommended?

A: Remote monitoring is recommended for clients who want to track their system's real-time performance, receive alerts, and optimize energy usage. It is especially valuable for commercial or industrial users and is available via WiFi or GPRS, depending on client preferences.

Q: Where can the On Grid Solar System be used?

A: This system is suitable for rooftop installations in residential, commercial, and industrial settings. It is designed to endure a wide range of environmental conditions, making it a preferred choice for diverse geographical locations that require grid-connected energy solutions.

Q: What are the primary benefits of the system's modular expandability?

A: Modular expandability allows users to start with an initial solar capacity and add more panels as energy demands grow or roof space increases. This flexibility ensures that the solar investment can scale over time without replacing the existing system, supporting future energy needs efficiently.
